Container — MPEG Transport Stream
One H.264 elementary stream wrapped in MPEG Transport Stream. Every file in this group was produced from the SAME encode with a stream copy, so the compressed video bytes are identical and the container is genuinely the only difference. The broadcast and HLS-segment container. Fixed 188-byte packets and no global index, so it can be cut at any packet boundary and still decode — which is exactly why streaming uses it.
Rendered preview of the ts file (28.5 KB). Download above for the original.
Specifications
- Resolution
- 480x270
- Fps
- 24
- Duration
- 1s
- Container
- MPEG Transport Stream
- Codec
- H.264 (libx264) — identical across this group
- Remux
- stream copy — video bytes are unchanged
- Audio
- none
What is a .ts file?
TS (.ts) is an MPEG transport stream — the container used for broadcast and HTTP Live Streaming segments — carrying packetized, timestamped MPEG video/audio in fixed 188-byte packets designed to survive transmission errors. (This .ts is video, not TypeScript.)
How to use this file
Use an example .ts segment to test transport-stream demuxers, HLS players, and TS-to-MP4 remuxing.
How to use this file for testing
“Container — MPEG Transport Stream” is a deterministic Novus Examples fixture for Video codecs, Conversion testing, Video QA. One source encoded as H.264, HEVC, AV1, VP9, MJPEG, and a ProRes-compatible mezzanine, across 8/10/12-bit and 4:2:0/4:2:2/4:4:4 — for testing decoder support, transcode pipelines, and container remuxing.
Documented properties for this file: 1s · 24 fps. Compare results against paired or grouped companions on this page when present (clean↔damaged, searchable↔scanned, or format twins) so scores stay reproducible across runs.
Download the file once, keep the path stable in CI or local scripts, and treat the spec table as the contract: dimensions, seeds, field lists, and roles are intentional. Corrupt or invalid samples are labelled as such — expect parsers to fail loudly rather than silently accept them.
Media fixtures are short and synthetic by design. Prefer waveform or transcript ground truth in the same group when measuring ASR, trim, upscale, or sync tools; do not assume broadcast-quality masters.
Code examples
npx tsx ts.ts # or: deno run ts.tsRelated files
