Container — AVI
One H.264 elementary stream wrapped in AVI. Every file in this group was produced from the SAME encode with a stream copy, so the compressed video bytes are identical and the container is genuinely the only difference. Microsoft's 1992 container. No B-frame timestamp support and a 4 GB practical limit, but enormous amounts of archived material still live in it.
Rendered preview of the avi file (41.7 KB). Download above for the original.
Specifications
- Resolution
- 480x270
- Fps
- 24
- Duration
- 1s
- Container
- AVI
- Codec
- H.264 (libx264) — identical across this group
- Remux
- stream copy — video bytes are unchanged
- Audio
- none
What is a .avi file?
AVI (Audio Video Interleave) is a legacy Microsoft multimedia container built on the RIFF structure that interleaves video and audio streams. It predates modern features, lacking robust support for advanced codecs, streaming, and multiple subtitle tracks. It remains common in older video files.
How to use this file
Use an example AVI to test RIFF-based demuxing, legacy codec handling, and converters that modernize older video into MP4 or MKV.
How to use this file for testing
“Container — AVI” is a deterministic Novus Examples fixture for Video codecs, Conversion testing, Video QA. One source encoded as H.264, HEVC, AV1, VP9, MJPEG, and a ProRes-compatible mezzanine, across 8/10/12-bit and 4:2:0/4:2:2/4:4:4 — for testing decoder support, transcode pipelines, and container remuxing.
Documented properties for this file: 1s · 24 fps. Compare results against paired or grouped companions on this page when present (clean↔damaged, searchable↔scanned, or format twins) so scores stay reproducible across runs.
Download the file once, keep the path stable in CI or local scripts, and treat the spec table as the contract: dimensions, seeds, field lists, and roles are intentional. Corrupt or invalid samples are labelled as such — expect parsers to fail loudly rather than silently accept them.
Media fixtures are short and synthetic by design. Prefer waveform or transcript ground truth in the same group when measuring ASR, trim, upscale, or sync tools; do not assume broadcast-quality masters.
Code examples
<video controls preload="metadata" width="640" src="avi.avi"></video>Related files
