Codec — ProRes-Compatible Mezzanine
The shared pan-city base plate encoded with FFmpeg prores_ks, profile 0 (proxy). An intra-only 10-bit 4:2:2 mezzanine written by FFmpeg's prores_ks encoder — the interchange shape editorial workflows expect. Described as ProRes-COMPATIBLE deliberately: this is FFmpeg's independent implementation, not Apple's encoder. Every clip in this group carries the identical picture, so a decoder-support matrix built from them isolates the codec as the only variable.
Rendered preview of the mov file (308.8 KB). Download above for the original.
Specifications
- Resolution
- 480x270
- Fps
- 24
- Duration
- 1s
- Frames
- 24
- Codec
- FFmpeg prores_ks, profile 0 (proxy)
- Container
- MOV
- Audio
- none
- Source
- pan-city base plate
- Chroma Subsampling
- 4:2:2
- Bit Depth
- 10
Testing contract
Expected to pass- Scenario
- Probe the file and decode it, then compare the decoded frames against another member of this codec matrix.
- Expected result
- 24 frames of 480x270 at 24 fps (1s) decode as FFmpeg prores_ks, profile 0 (proxy) in a MOV container, with no audio track. Every clip in this matrix is the same pan-city base plate, so a decoder that produces a different picture here than for the H.264 member has a codec bug rather than a source difference. Chroma subsampling is 4:2:2 at 10-bit, so this is the member of the group that survives a colour-correction round trip.
What is a .mov file?
MOV is Apple's QuickTime container, introduced in 1991 and the direct ancestor of MP4. ISO adopted its box structure as the basis of ISOBMFF, so the two are close relatives rather than rivals. Beyond video and audio it carries timecode tracks, edit lists, and reference movies: files of a few kilobytes that play only where the media they point at still lives. It also carries codecs MP4 does not, notably ProRes and Animation with a true alpha channel, which keeps it the working format of professional editing.
How to use this file
Use an example MOV to test QuickTime box parsing, timecode and edit-list handling, and MOV-to-MP4 remuxing, confirming that a stream copy is chosen when the codecs allow it, that an alpha channel survives where the target supports one, and that a reference movie is not mistaken for self-contained media.
How to use this file for testing
“Codec — ProRes-Compatible Mezzanine” is a deterministic Novus Examples fixture for Video codecs, Conversion testing, Video QA. One source encoded as H.264, HEVC, AV1, VP9, MJPEG, and a ProRes-compatible mezzanine, across 8/10/12-bit and 4:2:0/4:2:2/4:4:4, for testing decoder support, transcode pipelines, and container remuxing.
Documented properties for this file: 10-bit · 1s · 24 fps. Compare results against paired or grouped companions on this page when present (clean↔damaged, searchable↔scanned, or format twins) so scores stay reproducible across runs.
Download the file once, keep the path stable in CI or local scripts, and treat the spec table as the contract: dimensions, seeds, field lists, and roles are intentional. Corrupt or invalid samples are labelled as such, expect parsers to fail loudly rather than silently accept them.
Media fixtures are short and synthetic by design. Prefer waveform or transcript ground truth in the same group when measuring ASR, trim, upscale, or sync tools; do not assume broadcast-quality masters.
Code examples
