Pixel Format — 10-bit 4:4:4
10-bit 4:4:4 HEVC. Full chroma at 10 bits. Effectively an intermediate format only; almost nothing decodes it in hardware. Shipped in Matroska rather than MP4 on purpose: an exotic pixel format in an .mp4 would be advertised as browser-playable and then fail to decode. Every clip in this group is the same picture, so the pixel format is the only variable.
Rendered preview of the mkv file (17.5 KB). Download above for the original.
Specifications
- Resolution
- 480x270
- Fps
- 24
- Pixel Format
- yuv444p10le
- Bit Depth
- 10
- Chroma Subsampling
- 4:4:4
- Codec
- HEVC (libx265)
- Container
- Matroska
- Browser Playable
- no — by design, so the format is not misadvertised
What is a .mkv file?
MKV (Matroska) is a flexible open multimedia container that can hold virtually unlimited video, audio, subtitle, and attachment tracks with rich metadata and chapters. It is codec-agnostic and popular for high-quality video with multiple audio and subtitle options. It is a superset of the design behind WebM.
How to use this file
Use an example MKV to test multi-track demuxing, subtitle and chapter extraction, codec detection, and remuxing or transcoding pipelines.
How to use this file for testing
“Pixel Format — 10-bit 4:4:4” is a deterministic Novus Examples fixture for Video codecs, Conversion testing, Video QA. One source encoded as H.264, HEVC, AV1, VP9, MJPEG, and a ProRes-compatible mezzanine, across 8/10/12-bit and 4:2:0/4:2:2/4:4:4 — for testing decoder support, transcode pipelines, and container remuxing.
Documented properties for this file: 10-bit · 24 fps. Compare results against paired or grouped companions on this page when present (clean↔damaged, searchable↔scanned, or format twins) so scores stay reproducible across runs.
Download the file once, keep the path stable in CI or local scripts, and treat the spec table as the contract: dimensions, seeds, field lists, and roles are intentional. Corrupt or invalid samples are labelled as such — expect parsers to fail loudly rather than silently accept them.
Media fixtures are short and synthetic by design. Prefer waveform or transcript ground truth in the same group when measuring ASR, trim, upscale, or sync tools; do not assume broadcast-quality masters.
Code examples
<video controls preload="metadata" width="640" src="yuv444p10le.mkv"></video>Related files
